TECHNICAL SPECIFICATIONS
Project | Performance Indicators |
Model | LRF1017C |
Laser Wavelength | 1.54μm±0.02μm |
Eye- safety | Class Ⅰ |
Divergence Angle | ≤0.3 mrad |
Laser Energy | ≥300 μJ |
Launch Lens Diameter | Φ12 mm |
Receiver Lens Diameter | Φ40 mm |
Measuring Range （Reflectance 30%; visibility ≥ 12 km.） | NATO objective(2.3m×2.3m) ≥10 km |
Minimum Range | ≤50 m |
Ranging Frequency | 0.5Hz ~10Hz |
Number of multi-target detections | RS422 |
Ranging Accuracy | ±2 m |
Range Resolution | ≤30 m |
Precision Rate | ≥98% |
False Alarm Rate | ≤1% |
Pin-in-lead package model | J30J |
Supply Voltage | DC12 V |
Standby power consumption | ≤1.2W |
Average power consumption | ≤2 W |
Peak Power Consumption | ≤3W@10Hz |
Weight | ≤275g |
Dimension (L×W×H) | 107×62×72mm |
Operating Temperature | -40～+70 ℃ |
Storage Temperature | -55～+75 ℃ |
Impact Resistance | Meet the MIL-STD-810G testing standard |
Vibration Resistance | Meet the MIL-STD-810G testing standard |
