TECHNICAL SPECIFICATIONS
Project | Performance Indicators |
Model | LRF0405C |
Laser Wavelength | 1535±5nm |
Eye- safety | Class Ⅰ |
Divergence Angle | ≤0.6 mrad |
Laser Energy | ≥200 μJ |
Launch Lens Diameter | Φ8 mm |
Receiver Lens Diameter | Φ16 mm |
Measuring Range （Reflectance 30%; visibility ≥ 5km.） | NATO objective(2.3m×2.3m) ≥4000m Measuring human target(0.5m×1.7m) ≥1200m |
Minimum Range | ≤15 m |
Ranging Frequency | Single, 1Hz ~10Hz |
Number of multi-target detections | Up to 3 targets |
Ranging Accuracy | ±2 m |
Range Resolution | ≤20 m |
Precision Rate | ≥98% |
False Alarm Rate | ≤1% |
Pin-in-lead package model | FWF08002-S06B13W5M |
Supply Voltage | DC3～5 V |
Standby power consumption | ≤1 mW |
Average power consumption | ≤2.5 W @10 Hz |
Peak Power Consumption | ≤7 W @12 V |
Weight | ≤32±1 g |
Dimension (L×W×H) | 48mm×30.5mm×21 mm |
Operating Temperature | -40～+70 ℃ |
Storage Temperature | -55～+75 ℃ |
Impact Resistance | Meet the MIL-STD-810G testing standard |
Vibration Resistance | Meet the MIL-STD-810G testing standard |
